4K HD 64CH NVR Kit H.265 Video Compression App Motion Detection 8*14TB Embedded NVR Recorder Security Camera CCTV System Alarm

Functional Features:
1. Dual Gigabit Ethernet cards, supporting dual network IP settings and other applications.
2. Compatible with third-party cameras that adhere to ONVIF and RTSP protocols.
3. Supports the standard national GB28181 protocol.
4. Supports mixed access of H.265 and H.264 devices.
5. Supports preview, storage, and playback of 12MP high-definition network video.
6. Supports 2 HDMI ports, with HDMI supporting 4K and HDMI1 supporting 1080P output, and supports heterogeneous output.
7. Supports intelligent search and playback functions, effectively improving the efficiency of video recording retrieval and playback.
8. Supports up to 16-channel local synchronous playback.
9. Supports mobile client access.
10. Supports network detection (network traffic monitoring, network resource statistics) functions.

Technical Specifications
 Audio and video input
Video input: 64 channels
Access bandwidth: 320MB
Audio and video output
HDMI output: 1 channel, resolutions: 3840×2160, 2560×1440, 1920×1080, 1440×900, 1280×1024, 1280×720, 1024×768
HDMI2 output: 1 channel, resolutions: 1920×1080, 1440×900, 1280×1024, 1280×720, 1024×768
VGA output: 1 channel, resolutions: 1920×1080, 1440×900, 1280×1024, 1280×720, 1024×768
Audio output: 1 channel, HDMI/AUX interface (3.5mm)
Audio and video encoding parameters
Video recording resolution: 36 channels 12MP, 64 channels 8MP/5MP/4MP/3MP/1080P/720P
Synchronous playback: Immediate playback, regular playback, intelligent playback
Synchronous playback: 2 channels 12MP, 4 channels 8MP, 8 channels 4MP, 16 channels 2MP
Video recording management: Backup mode: regular backup, video clip backup
Hard disk drive
Type: 8 SATA interfaces
Maximum capacity: Each interface supports up to 14TB hard disk
External interfaces
Audio: 1 HDMI output, 1 3.5mm audio input/output jack
Network interface: 2 RJ45 1000M/100M/10M adaptive Ethernet
USB interface: 2 USB2.0
Network management: Network protocols
Support TCP/IP, IPv4, DHCP, NTP, RTSP, ONVIF, P2P, etc. network protocols Debate
Other
Power Supply: AC 100~240V (50/60Hz) ATX power input
Power Consumption (excluding hard disk)
≤ 8W (excluding hard disk)
Operating Temperature: -10℃ to +55℃
Operating Humidity: 10% to 90%
